VLSI & Embedded System Lab

Lab location: 3rd Floor, Room No. 310
Area of the lab in carpet: 100.37 sq. mt.
Cost of the equipments in the lab:

  • 2013-14 Rs. 716750/-
  • 2014-15 Rs. 261417/-
  • 2015-16 Rs. 1543465/-
  • 2016-17 Rs. 104000/-

Name of the Lab In-charge: Prof. P.V. Kasambe
Name of the Technical Assistant.: Mr. Nikhilesh Sariyam

This laboratory caters to the experiments for courses Basic VLSI, CMOS VLSI Design & MEMS.

The part of the lab is engaged in research activity for the final year students of Electronics. Software available and installed in VLSI lab: MENTOR Graphics, ConventorWare, COMSOL, VIVADO, Visual TCAD, Tanner tool, Aim SPICE, Microwind, PSPICE and MATLAB7.

These softwares are regularly used by the students for doing the experiments and projects.

Hardware available with related softwares are Zynq 7000 Development Kit, SENSIMER MEMS Platform, FPGA trainers, XILINX board, PAL logic Design Trainer, In-circuit emulator. Testing and measuring instruments like 100Mhz Digital Storage Oscilloscope is also available.

There are many prototype boards available from Texas Instruments University Program & Cypress University Program.
